OPR-1080M Micro AGC FTTH Optical Receiver
   Content
Description
OPR-1080M is designed for FTTH networks. Micro housing like a tap, external power supply which reduces the maintenance cost, Power input is in F connector, optical input in SC/APC or FC/APC, RF output in F connector.
With 2 stage LED indicator for optic input power, simple structure, easy to use and maintain.

Features
(1) Micro housing design
(2) Automatic Gain Control(AGC) circuit
(3) Designed for FTTH network
(4) 2-stage LED optical input power indicator
(5) Low consumption
(6) Aluminum die-casting housing

Technical  Specifications
Item
Unit
Parameters
Optic parameter
Input level range(PIN)
dBm
-10…-3,0
AGC range
dBm
-10…-3,0
Optical return loss
dB
≥40
Optical input wave length
nm
1100-1650
Max.input level
dBm
+3
Output power indicator
dBm
Diode LED indicator:
Red: PIN>-3
Green:-10
OFF:PIN<-10
Optical connector
N/A
SC/APC
RF Parameters
Frequency range
MHz
45~862
Output return loss
dB
≥14
Flatness of frequency response
dB
±1.0
Output level
dBuV
76
Nonlinear parameters
CTB
dB
≥60 *
CSO
dB
≥60*
CNR
dB
≥46**
RF Output Stability in AGC range
dB
±1.0
General Parameters
Voltage (external power supply)
VDC/mA
9/180
Power consumption
W
2
Output connector
N/A
F
Operating temperature range
°C
-20~+55
Weight without power supply
kg
0.1
Dimension(S*W*G)
mm
74*64(including F and fiber adaptor*17

Test Condition: CENELEC(85 channels), 0 dB slope, 3.5% OMI, -10dBm Optical power

Block Diagram


OPR-1080MS
