| Feature
1. Precise attenuation value
2. Excellent Reflectance
3. Perfect environmental stability and reliability
4. Dual window (1310nm/1550nm)
5. Attenuation from 0~30dB, 1dB increment
6. Flawless end face (Evaluating for ferrule end face images)
Technical parameters
|
Specification |
Value |
|
Item |
Single-Mode |
Multi-Mode |
|
Wavelength |
1310nm and 1550nm |
850nm and 1310nm |
|
Attenuation Range |
1310nm or 1550nm |
850nm or 1310nm |
|
Connector |
SC/ST/LC/FC,SC/APC,FC/APC,LC/APC |
SC/ST/LC/FC |
|
Attenuation Variation |
<10dB |
±0.5dB |
±1dB |
|
≧10dB |
±10% |
±15% |
|
Echo loss |
PC |
≧50dB |
≧30dB |
|
UPC |
≧55dB |
|
APC |
≧65dB |
|
Operation Temperature |
-40℃ ~ 75℃ |
|
Storage Temperature |
-40℃ ~ 85℃ | |
